Sliding Table Saw

CORMAK MJ45-KB-4 (1600)

CORMAK MJ45-KB4 - 1600 Panel Saw with Scoring Unit

The CORMAK MJ45-KB4 - 1600 is a professional panel saw with a scoring unit, designed for precise woodworking in carpentry workshops, production facilities, and service workshops. The machine combines industrial performance with the cutting accuracy required for processing furniture boards, MDF, and plywood.

Its stable construction, independent scoring blade drive, and carefully engineered guiding systems ensure repeatability and industrial-level cutting quality.

Main Advantages of the Machine
1600 mm aluminium sliding table – ensures smooth movement and precise guidance of the workpiece.
Independent 0.75 kW scoring motor – eliminates the risk of chipping and tearing on the underside of the material.
Powerful main saw motor – 5.5 kW (9 HP) motor provides efficient cutting performance even in hard materials.
Stable cast iron construction – resistant to vibrations, improving precision and operational safety.
Telescopic support arm with ruler and two stops – enables accurate positioning of the workpiece.
Cutting width up to 1250 mm – ideal for formatting large panels.
Ergonomic blade height and angle adjustment knobs – allow quick and tool-free setup.
Construction and Technology

The MJ45-KB4 - 1600 is built on a heavy cast iron body, providing high resistance to twisting and maintaining stable geometry throughout years of operation.

The cutting unit operates inside a rigid housing, which reduces vibrations and increases blade durability. The sliding table guidance system is based on hardened steel rods and precision linear bearings, ensuring smooth movement and eliminating play during cutting.

The machine is also equipped with a roller support table, making it easier to handle large-format materials.

Precision and Work Efficiency

Thanks to high blade speeds of up to 6000 rpm and a precise guiding system, the MJ45-KB4 panel saw provides perfectly straight and clean cutting edges, even when processing layered boards.
Bedpfotz Srlox Anrslp

The scoring blade, rotating at 8000 rpm, effectively eliminates laminate chipping and tearing. The adjustable cutting angle range of 0–45° allows complex formatting operations to be carried out with full control and accuracy.

Applications

The MJ45-KB4 - 1600 panel saw with scoring unit is designed for intensive use in:

woodworking workshops,
furniture manufacturing plants,
prototype departments,
architectural and model-making studios.

It is ideal for processing:

MDF boards,
HDF boards,
OSB panels,
plywood,
laminates,
solid wood.

The machine design enables quick setup changes and efficient production of both short series and individual projects without compromising quality.

Standard Equipment
1600 mm aluminium sliding table
Independently driven 0.75 kW scoring unit
Telescopic support arm with ruler and two stops
Roller support table
Folding parallel fence
Telescopic rip fence
Adjustment knobs for blade angle and height
Technical Specifications
Parameter Value
Sliding table length 1600 mm
Cutting width 1250 mm
Saw blade tilt range 0–45°
Cutting height at 90° 80 mm
Cutting height at 45° 56 mm
Maximum main blade diameter 315 mm
Maximum scoring blade diameter 125 mm
Main saw speed 4000 / 6000 rpm
Scoring blade speed 8000 rpm
Main motor power (S1/S6) 5.5 kW / 9 HP
Scoring motor power (S1/S6) 0.75 kW / 1.2 HP
Machine weight 460 kg
